35 Main Pipe Organ Stops Create sounds that lift spirits

The Imagine Series 235 delivers the most stunning sounds available in digital organs along with the ability to connect to wind-blown pipes, all in a beautiful 2-manual instrument. The organ has a total of 217 voices spread across 4 unique organ styles: American Eclectic, English Cathedral, French Romantic and German Baroque. On top of that, the organ features 28 premium orchestral voices. With 35 main stops, and the additional 99 Voice Palette™ stops, the Imagine 235 allows the organist to discover new possibilities.

Discover more

Main Pipe Organ Stops

DISCOVER

DISCOVER UNEQUALLED VERSATILITY

In addition to the 99 Voice Palette™ stops, the customizable Organ Stop Library provides another 55 pipe organ stops and ensembles while the Orchestral Library offers 28 premium orchestral voices. With a total of 217 choices at their fingertips, organists can create personalized registrations for any style and period of organ literature.

Opening up a new world of countless possibilities for organ registration, real-time stop selection enables advanced mix-and-match capabilities, going above and beyond the typical digital organ. Direct Streaming, a highly sophisticated technology featuring powerful ultra-fast computer processors and enhanced working memory, provides state-of-the-art operation and seamless integration.

BUILT TO THE HIGHEST STANDARD

The Imagine Series organs are carefully crafted to the standards of the American Guild of Organists (AGO) and showcase an elegantly designed and superiorly built console. A Rodgers exclusive 32-note radiating, velocity-sensitive AGO pedalboard is standard, as well as three Performance TouchTM velocity-sensitive keyboards with 128 levels of velocity sensitivity for orchestral voices. Dimmable illumination adorns the music desk, pistons, tabs, and pedal lights.


IMAGINE

Banner Imagine 235

Specifications

Imagine 235

VOICES

217 TOTAL VOICES

134 Organ stops (35 Main 99 Voice Palette Stops)

55 Organ Library stops and ensembles

28 Orchestral Voices

COUPLERS

3 plus 6 Library/MIDI Controls; Bass, Melody Swell and Melody Choir Couplers

MEMORY

50 levels per piston, unlimited memory banks with the USB drive

GENERAL PISTONS

10

DIVISIONAL PISTONS

5 Great, 5 Swell, 5 Pedal

SHOES

2 Expression (can be configured as 1 Expression, 1 Crescendo)

Dimensions

Depth with pedalboard: 46” (116.8 cm)

Depth without pedalboard: 27.7” (70.3 cm)

Height with music desk: 56.9” (144.5 cm)56.9” (144.5 cm)

Height without music desk: 47.8” (121.5 cm)

Width: 60” (152.4 cm)

Weights

Bench 46.3 lbs (21 kg)

Console 330.7 lbs (150 kg)

Pedalboard 79.4 lbs (36kg)

Total Weight 456.4 lbs (207 kg)

KEYBOARDS

Performance Touch™ velocitysensitive

keyboards

PEDALBOARD

32-note radiating velocitysensitive

AGO pedalboard for expressive playing of onboard percussive voices such as Piano, String Bass, or Timpani

TOE PISTONS

5 configurable, optional 10 or 14

TREMULANTS

2 (Great, Swell) Tremulants

AVAILABLE COLORS:

Dark

Oak

Medium

Oak

Light

Oak

Features

Imagine 235

  • High-Resolution Color LCD Display

  • Built-in and conveniently located headphone jacklocated headphone jack for quiet practice

  • Lighted tabs

  • Lighted music desk and kneeboard

  • Dimmable illumination for the entire console the entire console

  • Locking rolltop

  • Traditional wood veneer cabinet with deluxe wood cabinet with deluxe wood tambour

  • Music storage bench in matching finish

  • Deluxe adjustable bench (Optional)

  • Memory +/- pistons

  • User-friendly transposer thumb pistons affect live performance, playback of recorded songs, or Hymn Player selections

  • Organ Type piston immediately accesses American Eclectic, English Cathedral, French Romantic and German Baroque organ styles

  • On-board Hymn Player with 350 hymns common to many denominations

  • USB storage for registration data and recorded performances

  • Built-in demo songs, including music for worship and standard organ literature

  • MIDI In/Out and Local Off

  • Easy-to-use record and playback system, storable to USB

  • Pipe compatibility with wind blown pipeswind blown pipes

  • 50 internal memory banks

  • Programmable pedal F# sustain function and programmable kick-switch functionssustain function and programmable kick-switch functions

  • Built-in Page Turn technology for hands-free page turning controlled by toe pistons for music displayed on tablet (optional)

  • 12 reverb environments

  • 9 historic temperaments

  • 2.1-channel internal audio system: 2 channels x 50 watts full range audio + 1 channel x 160 watts subwoofer

  • Up to 10 external audio channels

  • 2-channel audio system for external satellite loudspeakers (optional)

  • Onboard voicing finishing and leveling controls

  • Pipe organ modeling technologies

Stoplist

GREAT

American Eclectic

Violone 16’

Principal 8’

Chimney Flute 8’

Gemshorn 8’

Octave 4’

Spitzflute 4’

Quint 2 2/3’

Super Octave 2’

Cornet V

Fourniture IV

Trumpet 8’

Chimes

Zimbelstern

Library/MIDI A

Library/MIDI B

Tremulant

Swell to Great

English Cathedral

Double Open Diapason 16’

Open Diapason 8’

Rohrflute 8’

Unda Maris II 8’

Principal 4’

Waldflute 4’

Twelfth 2 2/3’

Fifteenth 2’

Cornet IV

Mixture IV

Tromba 8’

French Romantic

Montre 16’

Montre 8’

Bourdon 8’

Gambe 8’

Prestant 4’

Flute Ouverte 4’

Quinte 2 2/3’

Doublette 2’

Cornet IV

Grand Fourniture IV

Trompette 8’

German Baroque

Prinzipal 16’

Prinzipal 8’

Rohrflöte 8’

Quintatön 8’

Oktave 4’

Gemshorn 4’

Nasat 2 2/3’

Super Oktave 2’

Kornett V

Mixtur VI

Trompete 8’

SWELL

American Eclectic

Bourdon Doux 16’

Geigen Principal 8’

Bourdon 8’

Viola Céleste II 8’

Octave 4’

Flute Traverse 4’

Nazard 2 2/3’

Octavin 2’

Tierce 1 3/5’

Plein Jeu IV

Double Trumpet 16’

Trumpet 8’

Oboe 8’

Library/MIDI A

Library/MIDI B

Tremulant

English Cathedral

Bourdon 16’

Horn Diapason 8’

Stopped Diapason 8’

Flûte Céleste II 8’

Octave Gamba 4’

Flute 4’

Quintflute 2 2/3’

Lieblich Piccolo 2’

Seventeenth 1 3/5’

Mixture III

Contra Trumpet 16’

Trumpet 8’

Cornopean 8’

French Romantic

Dulciane 16’

Montre 8’

Traverse Flute 8’

Voix Céleste II 8’

Prestant 4’

Flûte Octaviante 4’

Nasard 2 2/3’

Flute à Bec 2’

Tierce 1 3/5’

Fourniture III

Bombarde 16’

Trompette 8’

Hautbois 8’

German Baroque

Lieblich Gedackt 16’

Prinzipal 8’

Holzgedackt 8’

Schwebung II 8’

Oktave 4’

Flöte 4’

Nasat 2 2/3’

Waldflöte 2’

Quinte 1 1/3’

Scharff IV

Posaune 16’

Trompete 8’

Dulzian 8’

PEDAL

American Eclectic

Contra Bourdon 32’

Principal 16’

Subbass 16’

Bass Flute 8’

Choral Bass 4’

Mixture IV

Bombarde 16’

Trumpet 8’

Library/MIDI A

Library/MIDI B

Great to Pedal

Swell to Pedal

English Cathedral

Open Wood 32’

Open Diapason 16’

Bourdon 16’

Lieblich Bourdon 16’

Diapason 8’

Flute 8’

Fifteenth 4’

Mixture III

Tromba 8’

French Romantic

Contra Violon 32’

Principal 16’

Soubasse 16’

Prestant 8’

Bourdon 8’

Prestant 4’

Plein Jeu III

Bombarde 16’

Trompette 8’

German Baroque

Untersatz 32’

Prinzipalbass 16’

Bordun 16’

Oktave 8’

Gedeckt Bass 8’

Oktave 4’

Hintersatz III

Posaune 16’

Trompete 8’

Library

Imagine 235

RODGERS ORGAN AND ORCHESTRAL LIBRARY

The versatility of the Rodgers Imagine Series organs includes the built-in Organ and Orchestral Libraries, featuring 55 state-of-the-art organ stops and ensembles plus 28 premium orchestral voices.

The libraries are accessible on all manuals and pedals, through any of the two Library/MIDI controls per division. Each selection is user-voiceable and will save to a combination piston.

Classical Organ Library

1 Principal 32’

2 Lieblich Gedackt 16’

3 Dulciana 16’

4 Open Wood 16’

5 Spitzflute 16’

6 English Diapason 8’

7 Italian Principal 8’

8 Gamba Celeste II 8’

9 Aeoline 8’

10 Flute Harmonique 8’

11 Gross Flute 8’

12 Oktav 4’

13 Principal 4’

14 Rohrflöte 4’

15 Orchestral Flute 4’

16 Unda Maris II 4’

17 Violetta in Quinta 2 2/3’

18 Principal 2’

19 Salicional 2’

20 Piccolo 2’

21 Tierce 1 3/5’

22 Larigot 1 1/3’

23 Septième 1 1/7’

24 Sifflöte 1’

2 5 Jeu de Clochette II

26 Grave Cornet V

27 Tertian II

28 Pedal Grand Mixtur VI

29 Tierce Fourniture VI

30 Grand Mixtur IV-VIII

31 Klein Mixture III

32 Double Ophicleide 32’

33 Contre Bombarde 32’

34 Contra Fagott 16’

35 Pontifical Trumpet 16’

36 Rankett 16’

37 Trompet 8’

38 French Horn 8’

39 Hautbois 8’

40 Rohr Schalmei 8’

41 Dulzian 8’

42 Cromorne 8’

43 Regal 8’

44 Vox Humana 8’

45 Vox Humaine 8’

46 Tuba Mirabilis 8’

47 State Trumpet 8’

48 Chamades 8’

49 Trumpet De Fete 8’

50 Clarion 4’

51 2nd Clairon 4’

52 Schalmei 4’

53 16+4 Flute Celestes IV

54 16+4 Celestes IV

55 16+8+4 Celestes VI

Orchestral Library

300 Grand Piano

301 Electric Piano

302 Harpsichord 8

303 Harpsichord 8+4

304 Celesta

305 Orchestral Harp

306 Drawbars 1

307 Drawbars 2

308 Guitar

309 Acoustic Bass

310 String Ensemble

311 Slow Strings

312 Violin

313 Saxophone

314 Orchestral Trumpet

315 Bright Brass

316 Brass Ensemble

317 French Horn

318 Orchestral Flute

319 Bagpipes

320 Panpipes

321 Orchestal Oboe

322 Orchestral Clarinet

323 Choir Aahs

324 Choir Oohs

325 Organ Chimes

326 Handbells

327 Panpipes
